ODU AMC® NP

Quick-disconnect connector for military applications

Ruggedized design tested to MIL-STD-810H
Improved power contacts and USB® 2.0 capable¹
Cable Assembly
IP68, 20 m, 120 min waterproof versions

ODU AMC® NP is one of the world's most recognized connectors standardized on various Dismounted Soldier Systems. Due to its easy handling and robust break-away design, this connector is ideal for military and security power applications. You can also choose to have your connector expertly assembled to your specifications.

  • Ruggedized design tested to MIL-STD-810H
  • Improved power contacts and USB® 2.0 capable¹
  • Environmentally friendly, non-reflective black plating
  • Cable assembly
  • IP68, 20 m, 120 min waterproof versions
  • Plating: RoHS compliant black carbon
  • Compatible with: NATO STANAG 4695, Nett Warrior and GOSSRA
ODU AMC® NP quick video overview

Watch the 120 second connector overview highlighting ODU AMC® NP main features and applicability.

Robust break-away design

High-performance, quick-disconnect miniature connector. With a minimum of 2,000 mating cycles, improved power contacts with USB® 2.0 capabilities¹ and up to IP68, 20 m, 120 minutes.

Assembly according to your specifications

This connector gives a significant competitive advantage to equipment manufacturers that want a highly reliable and readily available connectivity solution. ODU provides complete cable assembly integrated solutions as well as rapid prototyping for custom/hybrid connectors.

Ruggedized design tested to MIL-STD-810H

This metal, rugged connector enhances a soldier’s ability to communicate in the battlefield and is tested to applicable technical requirements.

ODU AMC® NP – Applications

Easy handling and robust: ODU AMC® NP is mainly used for tactical soldier batteries, PDU (power distribution units), CWB (Conformable Wearable Batteries) and C4ISR peripherals for the transmission of USB 2.0 signals¹ and power. It is compatible with open architecture standards such as NATO STANAG 4695, Nett Warrior and GOSSRA (General Open Structure Architecture).

Compare products

ODU AMC®
ODU AMC®
ODU AMC® Easy-Clean
ODU AMC® Easy-Clean
ODU AMC® High-Density
ODU AMC® High-Density
ODU AMC® Threaded
ODU AMC® Threaded
ODU AMC® Series T
ODU AMC® Series T
ODU AMC® NP
ODU AMC® NP
IP Class matedUp to IP6K9KUp to IP6K9KUp to IP6K9KUp to IP6K8Up to IP6K8IP68
IP Class unmatedIP68IP6K8IP68IP68IP68IP68 (for overmolded and potted connectors only)
KeyingPin and groovePin and groovePin and groovePin and groovePin and groovePin and groove
Mating-cycles> 5,000> 5,000> 5,000> 2,000> 500> 2,000
Termination technologiesSolder, PCBSolder, PCBSolder, PCBSolder, PCBSolder, Crimp, PCBSolder, Crimp, PCB
Shell materialAluminumAluminumBrassAluminumAluminumAluminum
PlatingRutheniumRutheniumRutheniumTin-NickelTin-NickelRoHS compliant black carbon
Operating temperature range–51 °C to +125 °C–51 °C to +125 °C–51 °C to +125 °C–51 °C to +125 °C–65 °C to +175 °C–18 °C to +71 °C

¹The contact arrangement of an ODU data transmission connector differs from a standard data transmission connector due to the robust ODU specific design. However, the ODU design meets the electrical specifications of the respective standard data transmission protocol.
