Chrome coating

Thanks to its innovative chrome surface coating, the ODU AMC® High‐Density series is suitable for applications that must be autoclavable. In other words: This connector can also be used in the medical field. We offer different sizes, contact variants, and configurations.

High‐density configurations

In addition to signals, the ODU AMC® High‐Density can also transmit current up to 15A and various data protocols such as USB® 3.2 Gen 1x1, 5A.

Chrome coating

High‐density configurations

In addition to signals, the ODU AMC® High‐Density can also transmit current up to 15A and various data protocols such as USB® 3.2 Gen 1x1, 5A.

ODU AMC® HIGH-DENSITY

Metal connectors with an especially high contact density

High contact density

High‐speed data technology

Salt water resistance

360° shielding

You need technical details, CAD data, would like to order samples or buy online?

Start Product Finder

also available at

Premium quality in the smallest space: The ODU AMC® High‐Density series incorporates up to 27 contacts from a diameter of 7 mm. Even under adverse conditions, these connectors ensure a long service life, as well as excellent shock and vibration resistance.

Waterproof in accordance with protection class IP6K8
Screw‐lock or break‐away function
Operating temperature: –51 °C to +125 °C
2 – 27 contacts / 3 sizes
Long service life with more than 5,000 mating cycles
Diameter from 7 mm to 15 mm

Compare series

ODU AMC® HIGH‐DENSITY – applications

Flexible, reliable, and compact: ODU AMC® HIGH‐DENSITY is the right solution for military and security applications, test and measurement technology, as well as industrial electronics.

All suitable applications

Compare products

	ODU AMC®	ODU AMC® Easy-Clean	ODU AMC® High-Density	ODU AMC® Threaded	ODU AMC® Series T	ODU AMC® NP
IP Class mated	Up to IP6K9K	Up to IP6K9K	Up to IP6K9K	Up to IP6K8	Up to IP6K8	IP68
IP Class unmated	IP68	IP6K8	IP68	IP68	IP68	IP68 (for overmolded and potted connectors only)
Keying	Pin and groove	Pin and groove	Pin and groove	Pin and groove	Pin and groove	Pin and groove
Mating-cycles	> 5,000	> 5,000	> 5,000	> 2,000	> 500	> 2,000
Termination technologies	Solder, PCB	Solder, PCB	Solder, PCB	Solder, PCB	Solder, Crimp, PCB	Solder, PCB
Shell material	Aluminum	Aluminum	Brass	Aluminum	Aluminum	Aluminum
Plating	Ruthenium	Ruthenium	Ruthenium	Tin-Nickel	Tin-Nickel	RoHS compliant black carbon
Operating temperature range	–51 °C to +125 °C	–51 °C to +125 °C	–51 °C to +125 °C	–51 °C to +125 °C	–65 °C to +175 °C	–18 °C to +71 °C
